optic fiber cable:GYTS cable:aerial duct cable from China manufacturer - Zhejiang JinYuan Copper International Co., Ltd.

optic fiber cable:GYTS cable:aerial duct cable

Price:	0.1 USD
Payment Terms:	T/T,L/C
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: ZJ-11-08

Production Capacity: 2000 km/MONTH

Delivery Date: 15 days

Type: Low Voltage

Jacket: PE

Brand Name: OEM

Means of Transport: Ocean

Packing: Standard export packing or ...

Application: Telecommunication

Insulation Material: PE

Conductor Material: Others

GYTS outdoor aerial duct armored optic fiber cable
1.armored by steel wires
2.suitable for Direct Buried installation
3.have very good tensile

GYTS outdoor Armored optic fiber cable
GYTS outdoor aerial duct armored optic fiber cable

1. Specification:

Loose tube style,optical fiber Cable with metallic central strength member of FRP and moisture barrier inner sheathed.Cable protected by laminated aluminum tape a corrugated steel armouring and a black PE oversheath for protection against mechanical damage and termite or rodent attack, suitable for direct buried or aerial application.Tubes contain optical single-mode or multimode fibers colour coded as per color coding scheme.

2. Application:

   -.Usable in Duct or Aerial
   -. Long-haul communication system
   -.Junction communication system
   -. Subscriber network systems
   -.Local area network systems

3.Characteristics:

F.Number	Dia.	Weight (kg/km)	Min.Bending R. St.(mm) Dy.(mm)		Min.allowableT.S. S.T.(N) L.T.(N)		Min.allowableC.L. S.T.(N/100M)L.T.(N/100M)
2~36	15.9	233	199	398	3000	1000	3000	1000
38~72	17.3	274	216	433	3000	1000	3000	1000
74~96	18.9	328	236	473	3000	1000	3000	1000
98~120	20.6	380	258	515	3000	1000	3000	1000
122~144	22.4	442	280	560	3000	1000	3000	1000
146~216	22.7	455	284	568	3000	1000	3000	1000
