RG59 ; rg59+2 core from China manufacturer - Zhejiang JinYuan Copper International Co., Ltd.

Payment Terms:	T/T,L/C
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: ZJ-083101

Production Capacity: 600 kilometers montly

Delivery Date: 15 days

Type: Coaxial

Weight: 40kg/km

Temperature Rating: 80 centigrade

Means of Transport: Ocean,Land,Air

Packing: standard expprt packing

Application: Telecommunications

Brand Name: oem

Number of Conductors: 1

Impedance: 75Ω

RG59/B coaxial cable
1) 0.643mmBC + 3.71mmSolid PE +95% Tinned Copper Braiding +6.15mm PVC

RG59/B coaxial cable
1) 0.643mmBC + 3.71mmSolid PE +95% Tinned Copper Braiding +6.15mm PVC
Mechanica properties:
Cable Temperature Rating: 80 centigrade

Electrical Properties:
Impedance: 75Ω

Application:
Used as a distribution cable for indoor CATV, CCTV systems and as a connection cable for satellite systems where lower attenuation required.

ATTENUATION @ 68 ºF (20ºC )
FREQUENCY	Maximum (dB/100m)	Maximum (dB/100ft)
	100m	100ft
5MHz	1.9	0.58
83MHz	6.4	1.95
211MHz	10.0	3.05
250MHz	10.82	3.30
300MHz	11.64	3.55
400MHz	13.61	4.15
600MHz	16.73	5.10
865MHz	20.01	6.10
1000MHz	21.49	6.55
IMPEDANCE	Ohm	75 ± 3
CAPACITANCE	pF/m	52 ± 2
VELOCITY RATIO	%	82%
RETURN LOSS AT	VHF5-300MHz	22dB
	UHF300-960MHz	20dB
SCREENING EFFICIENCY	VHF5-50MHz	85dB
	MORE THAN UHF200MHz	90dB
